UTP jacks in HIL E 15

VLAN579 caad-b-ip 129.132.32.128 (Building IP)

Telephone (Siemens)

Telephone (IP)

VLAN354 arch-caad-1 129.132.27.0 (Hovestadt CAAD HBT D-ARCH)

auf VLAN170 arch-stud-1 129.132.18.0 (NDS (Studentennetz) für die Fix installierten PCs im NDS-Raum))

auf VLAN524 docking-hix 172.30.24.0 (n.ethz-netz, für Airport, und für Laptop-Kabel (via valid.ethz.ch))

Unknown

-- TorstenSpindler - 21 Jul 2005

Attachment sort Action Size Date Who Comment
UTP.png manage 243.0 K 18 Oct 2005 - 15:21 TorstenSpindler UTP Jack Map for ETH E15
utp.eth.svg manage 20.7 K 18 Oct 2005 - 15:21 TorstenSpindler SVG Source, edit with inkscape
